Automatic belt drive garage door opener rolling code high performance code capture
Automatic garage door belt drive sectional garage door DC opener /motor/operator GS/CE certified
The motor can be widely used in houses and be easily installed on garage doors.At same time,It has high safety and convenience performance.
2, With Double-channel and humanized design of the remote control, self lock of the keys, operate sensitive and save, the
remote distance applicable to more than 25M.
3, Automatic power check function, read the running power automatic and it will stop automatically if obstructed during
the process of rising and falling.
4, Flexible starting and stopping technique.
5, Electronic limit device, which can be memory and restore automatically.
6, Door opener can be self locked in case of power failure.
7, Safety and low voltage of lighting.
Type: Garage Door Opener
Place of Origin: Guangdong, China (Mainland)
Brand Name: ZHONG TIAN
Standard Force: 600N/800N/ 1000N
Apply Door Area: 7㎡12㎡/ 15㎡
Rail Length:3000mm, 3300mm, 3600mm, 3900mm
Remote Frequency: 433.92MHZ
Remote Distance: 25-35m
| Item | ZTGD(|||)600 | ZTGD(|||)800 | ZTGD(|||)1000 |
| Pull and Push Force | 600N | 800N | 1000N |
| Rated Voltage | AC:220-240V(50HZ-60HZ) | AC:220-240V(50HZ-60HZ) | AC:220-240V(50HZ-60HZ) |
| Motor Power | 110W Max | 154W Max | 200W Max |
| Apply Door Size | 7㎡ Max | 12㎡ Max | 15 ㎡ Max |
| Rail Length | 3m,3.3m,3.6m,3.9m | 3m,3.3m,3.6m,3.9m | 3m,3.3m,3.6m,3.9m |
| Opener Noise | Below 60db | Below 60db | Below 60db |
| Running Speed | 120mm/s | 120mm/s | 120mm/s |
| Remote Distance | 50m | 50m | 50m |
| Remote Control Code | Rolling Code | Rolling Code | Rolling Code |
| Remote Frequency | 433.92MHZ | 433.92MHZ | 433.92MHZ |
| Auto Lighting | Turn off after 3~5minutes | Turn off after 3~5minutes | Turn off after 3~5minutes |
| Temperature range | -45℃~70℃(-49℉~+158℉) | -45℃~70℃(-49℉~+158℉) | -45℃~70℃(-49℉~+158℉) |
1. Remote Controls
There are two pcs for one set, and the style as above picture
2. Chain or Belt Drive Rail
the length of Rail can be customized according your requirements
3. Hardware Bag
1 Photocell
To prevent serious injury or death from closing garage door. Can work with all ZhongTian openers.
2.Wireless Keypad
3. Wireless Wall-mounted remote control
For use inside of the garage or/and room to enable access to the
garage. Can work with all ZhongTian openers.
4. Emergency Lock
For opening door from outside of garage when power off. Can work
with all ZhongTian openers.
5. Back-up Battery
For opening door when power off
